Bag Handle Metal Bracket

Structural Support Between the Handle and Case Body

The Bag Handle Metal Bracket connects a carrying handle to the case body. It provides a stable installation point and helps transfer lifting forces from the handle into the case structure.

The product is suitable for hard-shell suitcases, flight cases, business cases, cosmetic cases, toolboxes, instrument cases, and briefcases that are lifted frequently.

Depending on the case construction, the bracket can be produced by die casting, stamping, or machining. It may be designed as a fixed structure, a movable structure, or a mounting bracket for a spring-return handle.

Available materials include zinc alloy, iron, stainless steel, and aluminum alloy. Buyers can select a material according to the total case weight, case-body material, surface appearance, frequency of use, and structural requirements.

Mounting Dimensions and Complete Assembly Strength

The installation-hole spacing is 20–80 mm and can be customized according to the existing holes in the case or the customer's drawing. Bracket height is 8–35 mm.

A larger mounting base can help distribute concentrated stress created during lifting. Screws, rivets, washers, or a backing plate may also be used to improve the connection between the bracket and case body.

The reference load capacity is 150–500 N per pair. However, the actual capacity is also affected by the case-wall thickness, backing-plate area, fastener specification, installation-hole position, and handle structure.

For suitcases, toolboxes, and other products that experience repeated lifting, buyers should test the complete installed handle assembly. A static figure for an individual bracket cannot replace lifting and fatigue tests on the complete case system.

The Bag Handle Metal Bracket should therefore be selected as part of a complete mounting solution rather than as an isolated metal part.

The surface color can be coordinated with locks, corner protectors, trolley components, and other case hardware.

Zhejiang Tongtai Lock Industry can adjust the hole spacing, bracket height, mounting-base dimensions, and fastening method according to a technical drawing, physical prototype, or complete handle assembly.

The company has an independent research and development team of approximately five people. The team can improve an existing model or develop a matching structure for a new case project.

Sampling and pre-production sample confirmation are supported before volume manufacturing. Buyers can use the samples to check the mounting holes, handle movement space, surface color, and complete assembly effect.

This step helps reduce the risk of interference, incorrect hole alignment, or unsuitable hardware proportions during later case assembly.

The factory's order process covers component processing, assembly, quality inspection, packaging, warehousing, and shipment.

Formed brackets are checked for dimensions and mounting-hole positions. After surface treatment, the factory inspects the color, scratches, blistering, and other visible appearance defects. Process inspections are carried out during production, and every finished product is checked before packaging.

For approximately 10,000 standard pieces, the usual production period is around 25 days. Customized orders above 5,000 pieces normally require 30–35 days when mold-making time is excluded.

The factory uses a production management system to arrange orders and provide updates at key production stages. This helps buyers coordinate the purchasing schedules for the case body, handle, and related hardware.
